If the cable elevator operates according to the principle:

Cable traction elevators are driven by electric motors. The force from the motor is transmitted through a system of pulleys and steel cables, helping the cabin move up or down.

Then the hydraulic elevator:

• Use piston drive mechanism.
• The system operates based on the thrust of hydraulic oil pumped into the cylinder.
• As the oil pressure increases, the piston moves vertically, thereby raising or lowering the cabin.

Outstanding features of hydraulic elevators

• Load capacity range: 200kg , 300kg , 400kg
• There are 2 - 5 floors in operation.
• Smooth, stable and safe operation

Structure of hydraulic elevator

Application of hydraulic technology:

Hydraulic technology has long been widely applied in many fields, including:

Industrial production lines, aviation and automobiles, agricultural machinery. Wind turbines. Mining. Transportation and construction. Today, hydraulic technology continues to be developed and effectively applied in the field of elevator transmission, especially systems.thang máy thủy lực.

Working principle of hydraulic elevator:

• Operates on a hydraulic piston mechanism, usually located at the bottom of the pit or just below the floor.
• When hydraulic oil is pumped into the cylinder, the pressure created pushes the cabin lift piston to move upward.

Hydraulic elevator systems are also supported by:

• Guide rails: ensure the cabin moves in the right direction
• Pulley and cable: support the lifting process, increase stability

Thanks to this design, the cabin always moves in a stable, safe and smooth way.

Advantages of hydraulic elevators.

Advantages of hydraulic elevators:

Low investment cost:

1. Simple structure, few components, reduced installation costs compared to traditional elevators.
2. Simple structure, safe operation: Using piston drive system. → reduce the risk of mechanical failure, increase stability and safety during operation.

Save installation space:

• No counterweight required → optimizes cabin size and maximizes elevator shaft space.
• Especially suitable for family homes and buildings with limited space.

No deep pit required:

• Can be installed without a pit, or with a shallow pit of 10–20 cm.
• Flexible with many site conditions, including renovation projects.

Low top floor height:

• Only need the top floor height of about 2,600 mm → suitable for low-rise buildings, helping to save building height.

Disadvantages of hydraulic elevators

Limitations of hydraulic elevators:

Slow operating speed:

• Moves about 15 meters/minute, slower than cable elevators. Suitable for low-rise buildings that do not require high speed.

Serving height limit:

• Maximum efficiency within 4 floors (10–13 metres), due to piston travel and system efficiency limitations.

Occupy equipment installation space:

• The pump and oil tank are usually located on the ground floor → affecting the usable area or aesthetics if not designed properly.
• There is a risk of hydraulic oil leakage if poorly maintained.

High maintenance and repair costs:

• There are few specialized units and technicians, so maintenance and repair costs are often higher than other popular types of ladders.

Price List & Specifications, Dimensions: Hydraulic Elevator

How to Make a Hydraulic Elevator Quotation (Automatic)

Chương trình báo giá thang máy thủy lực We build and operate it completely automatically to ensure accuracy and consistency. Based on this quote, we create a contract appendix and transfer it directly to the production department, creating a closed process, minimizing unnecessary problems. As a result, work efficiency is significantly improved, while helping to optimize costs, bringing more competitive prices to customers.

Please watch the entire video to understand the structure of hydraulic elevators.

Compare Advantages & Disadvantages of Hydraulic Home Elevator Models

We respectfully send you the price list of the product lines.thang máy thủy lực. Let's analyze in detail the advantages and disadvantages of each type. This information is presented clearly to help you easily compare and choose the elevator solution that best suits your needs and actual conditions.

If you need more information or in-depth advice, please do not hesitate to contact us at Hotline: 0707.025.789 . Our team of experts is always ready to support and answer all your questions enthusiastically and quickly.

Price List of Hydraulic Elevators - For Home Use

Factors determining the price of hydraulic elevators

Factors affecting the cost of hydraulic elevators:

Types of pit frames and enclosures:

• Concrete frame, masonry wall: Lower cost due to cheap materials and simple construction.
• Steel frame, aluminum wall or tempered glass: Higher cost due to more complex materials and technical requirements.

Number of floors served:

• The more floors (2–5 floors), the more complex the system → equipment and construction costs increase accordingly.

Cabin and elevator shaft dimensions:

• The larger the installation area → the greater the volume of materials such as steel, glass, walls, cabin floors, etc. → the higher the total investment cost.

Types of floor doors:

• Automatic doors: Convenient, highly aesthetic but higher cost due to the need for additional motors, sensors and control systems.
• Manual (semi-automatic) doors: Lower cost, suitable for budget-conscious people.

Hydraulic Elevator Size & Load Capacity

The characteristics of mini elevators are usually installed for houses with compact areas, or renovated houses. Therefore, the factor of saving space is extremely important. Therefore, when designing glass elevators. Designers often pay attention to the factor of saving space. Increase space and increase light for the house. Therefore, priority is given to using steel or aluminum frames and glass walls for the elevator shaft. The size and load capacity of mini hydraulic elevators that do not require digging a pit are shown in the table below.

1. Hydraulic elevator size table

Common size chart for your reference. Depending on actual conditions, you can choose any size. For each size suitable for the house architecture. Hoang Sa Viet Sankyo will offer the most reasonable solutions.

This size chart is for indoor hydraulic elevators . For outdoor pitless elevators , the choice depends on actual conditions.

2. Hydraulic elevator floor plan & cabin dimensions

Pit technical drawing and standard cabin size of glass frame elevator line are described in pictures on the following slides.

Click left < or right > to view image

Cabin size is for reference only. For each actual project, we will optimize the best cabin size for you, with many available solutions at Hoang Sa Viet Elevator.

5 Safety Features of Hydraulic Elevators

Just like other home elevator products. Mini hydraulic home elevators need to meet all safety criteria. However, regarding inspection, some backpack elevator models have not been approved for inspection by the inspection department.

Therefore, Hoang Sa Viet Sankyo once again advises you if the installation area meets the standard of 1000x1000 or more . Please choose the product lines that meet the inspection standards (according to the table above). Some elevators without cabin doors must be equipped with infrared safety curtains (photocell) . Below are the necessary safety features of glass-cage family elevators.

See More Hoang Sa Viet Hydraulic Elevator Products

Thang Máy Gia Đình

Thang Máy Không Hố Pit

Real Project Video

Maintenance and Repair Services

List of National Dealers

1. Automatic rescue system - hydraulic elevator (ARD)

The Auto Rescue Device (ARD) is one of the most important safety features of a home hydraulic elevator , protecting users in the event of a sudden power outage. When the main power source fails, the ARD will automatically activate the backup power source, bring the cabin to the nearest floor and open the door for people inside to escape safely. This feature is especially useful for families with young children or the elderly, ensuring that no one is trapped in the cabin for long when an incident occurs.

In addition, the ARD system also helps protect components and electronic equipment in the elevator from the risk of damage due to sudden power outages. Thanks to that, the home elevator is not only safer but also increases its lifespan, minimizing maintenance and repair costs during long-term use.

2. Gornover overspeed control device - hydraulic elevator

Overspeed control device, Gornover in hydraulic elevators is a mandatory element in all pitless elevators. When the elevator runs beyond the permitted speed or in the rare case of cable breakage, this device will automatically activate, hold the cabin and prevent the cabin from falling freely. Thanks to that, the user's life is maximally protected against any unexpected risks.

The Gornover overspeed control system not only works effectively in emergencies, but also helps control elevator operations in a state of maximum safety, especially for families with young children or the elderly who often travel by elevator.

3. Anti-jamming door with photocell sensor - hydraulic elevator

Photocell sensors, also known as infrared safety curtains, are one of the highly appreciated safety features of hydraulic elevators . This sensor system is installed on both sides of the elevator door, capable of detecting obstacles during the door opening/closing process. When encountering an obstacle, the sensor will automatically open the door or stop the closing process, preventing the door from getting stuck, protecting the safety of users, especially children and pets.

Thanks to the photocell sensor, every family member can safely use the elevator without worrying about getting their hands, feet stuck or other unexpected incidents. This is one of the necessary and almost mandatory features for modern home elevators.

4. Overload alarm device for cabin - hydraulic elevator

The overload alarm is a safety feature in hydraulic elevators that detects when the total weight of people and objects in the cabin exceeds the allowable level. As soon as overload is detected, the system will emit an audible warning signal, and the elevator will not operate until the load returns to a safe level. This helps protect important components such as the motor and cable, limiting the risk of damage and accidents.

Equipping an overload warning device helps users raise their safety awareness, avoiding unintentional actions that endanger themselves and the equipment. This is a simple but effective solution, contributing to prolonging the life of the glass elevator.

5. Door open control feature - hydraulic elevator

The door-opening control feature in hydraulic elevators is a solution to prevent elevator door-related incidents. If the cabin door or landing door is not completely closed, the elevator will not operate to ensure user safety. This system is often combined with magnetic sensors, which help to accurately control the door status.

Thanks to this feature, the risk of accidents due to doors being opened or not fully closed is completely eliminated. Users will also receive timely warnings, helping to raise awareness of protecting themselves and their family members when using the elevator.

8 Frequently Asked Questions When Installing Hydraulic Elevators

1.Nhà cải tạo có nên lắp thang thủy lực?

Renovation houses often have little space to accommodate traditional elevators. Usually, the area of ​​renovation houses only allows for repairs of about 1-1.5m2. In addition, it is not convenient to construct a pit. Therefore, hydraulic elevators without pits are very suitable for renovation houses.

2. To install a hydraulic ladder in the middle of a staircase, what is the minimum area required?

Many Vietnamese families choose to install compact hydraulic ladders in the space between stairs to maximize space, ensure aesthetics and convenience for movement.

Installing an elevator in the middle of a stairwell often requires careful survey of the structure, distance between the stairs and the open space. These models thang thủy lực mini nhỏ gọn chỉ 1 m2 often preferred for its ability to maximize natural light, creating a spacious and luxurious feeling for the lobby area.

In addition, the foundation reinforcement and safety system installation plans are also carefully calculated to ensure stable, smooth and long-lasting operation. To install an elevator in the middle of a staircase, the following requirements are required:

• Clear width between stairs, minimum 85cm (850mm)
• The minimum required clear depth between the stairs is 100cm (1000mm)
• Minimum required top floor height 2600mm

3. Can a mini hydraulic ladder be installed in a skylight ?

• Skylights are a common architectural highlight in modern townhouses, providing natural light and air circulation. Many families wonder if it is possible to take advantage of this space to install a glass-cage hydraulic elevator . The answer is absolutely possible, if you choose an elevator solution that is suitable for the space and structure of the skylight.
• With skylights ranging in size from 0.9m2 to 1.5m2 , hydraulic ladders are the ideal solution, both saving space and increasing the aesthetic value of the house.
• When installing an elevator at O ​​Thoang - Gieng Troi, it is necessary to survey, come up with a specific plan, and also need to make preliminary renovations to convert the skylight into a standard elevator shaft.

Contact Hoang Sa Viet now for the best solution in terms of cost and quality...!

4. Can a hydraulic ladder be installed on the front balcony?

This is an ideal location to install a compact hydraulic ladder for houses with limited interior space. Utilizing the balcony space helps expand the utility, enhancing the usability of the house in an optimal way.

Installing an elevator on the front balcony of the house not only creates an architectural highlight but also saves floor space inside. Pitless hydraulic elevators or outdoor elevators are specially designed to be waterproof, resistant to sun and rain and ensure absolute safety.

In particular, this solution is suitable for townhouses and villas aiming for a luxurious, modern living space, convenient for all family members to move around without affecting the structure of the house.

To install an elevator on the balcony (outdoor elevator). A detailed solution is needed for balcony design, renovation, roof design, waterproofing, and water resistance to be able to use it for a long time. Waterproofing is the most difficult measure. However, with a team of experienced experts from Nidec Sankyo Elevator, we will survey and propose the best solution with you to achieve efficiency and optimize costs...

5. Should a circular hydraulic elevator be installed in the middle of the staircase?

Circular hydraulic elevators , or semicircular elevators, are an ideal choice for installation in the middle of circular staircases. This is to enhance aesthetics and optimize space. However, currently, circular hydraulic elevator models are often twice as expensive as rectangular elevators.

The installation of circular hydraulic elevators is also implemented by few units. At Nidec Sankyo Elevator, we are developing circular elevator models with cheaper prices from 700-900 million VND . Please contact us for more details.

6. Do I need permission to renovate my house and install a hydraulic elevator?

According to the provisions of the Construction Law, when renovating or repairing a house, the homeowner must submit an application for a renovation permit to the People's Committee of the ward/commune where he/she resides. However, in reality, mini elevators are devices installed in the interior, have a compact size and do not affect the load-bearing structure of the house. Therefore, in many cases, the installation is not considered a major change in construction.

For renovated houses, mini elevators are often installed in the space between stairs, helping to maximize space without affecting the usable area or adjacent buildings. In the case of installing outdoor elevators, it is necessary to consider more carefully factors such as urban landscape, building setbacks, traffic safety and the impact on neighboring houses.

In fact, many families when installing mini elevators in their homes often do not carry out construction permit procedures, because the equipment does not affect the main architectural part. However, this also depends on the specific regulations and the level of construction order management of each locality. To avoid legal risks, homeowners should contact local authorities or construction consultants in advance for detailed instructions.

7. How much does it cost to use the hydraulic elevator for electricity each month?

Electricity cost for using mini hydraulic elevator for home

For mini elevators used in homes, monthly electricity consumption costs will depend on factors such as: elevator technology (hydraulic, traction cable, screw shaft...), load capacity, motor capacity and actual frequency of use.

To help customers have a clearer picture, Hoang Sa Viet Elevator would like to give an estimate of electricity costs as follows:

• Small family, low frequency use: about 200,000 - 300,000 VND/month
• Large family, frequent use: about 300,000 - 500,000 VND/month

This is a relatively reasonable cost, equivalent to the use of some other household electrical appliances, such as air conditioners or water heaters. In addition, modern elevators are also integrated with energy-saving technology, helping to reduce long-term operating costs.

8. How much does it cost to maintain and service a hydraulic elevator each month?

Hydraulic elevator warranty & maintenance policy at Hoang Sa Viet

For home elevators and building elevators supplied and installed by Hoang Sa Viet, customers will enjoy free warranty and maintenance for the first 2 years from the date of delivery.

After the warranty period, Hoang Sa Viet applies a monthly maintenance package with the following costs:

• Office elevator: 800,000 VND/month
• (periodic maintenance every 1-2 months/time depending on usage level)
• Home elevator: 600,000 VND/month
• (periodic maintenance every 2 months)

The above costs include technical inspection and maintenance items to ensure the elevator operates stably, safely and prolongs the life of the equipment. The maintenance frequency can be flexibly adjusted according to the needs and actual usage status of each project.

Introducing Hoang Sa Viet - Specializing in Hydraulic Elevators

Choosing a reputable supplier to install hydraulic elevators is a decisive factor in product quality and after-sales service. Hoang Sa Viet Elevator is proud to be a trusted partner of thousands of customers nationwide, providing high-quality glass elevator solutions, reasonable prices and dedicated, professional service.

Nidec Sankyo Elevator Hydraulic Elevator Products

1. Many years of experience in making hydraulic elevators, reputable in the market

Hoang Sa Viet is a company with more than 10 years of experience in the field of supplying and installing mini hydraulic elevators for families. With a team of experienced, highly skilled and well-trained technicians, we are committed to bringing customers projects that meet high standards of quality, safety and aesthetics.

Hoang Sa Viet brand has affirmed its reputation through thousands of large and small projects across the country. In addition, we are always a pioneer in applying new technology through cooperation with reputable partners such as Nidec Elevator, to bring optimal, cost-saving and durable elevator solutions for each customer's actual needs.

2. Team of professional and dedicated consultants

One of the outstanding strengths of Hoang Sa Viet is the team of professional, experienced and dedicated consultants. Each customer will be supported in detail throughout the process - from choosing the elevator model suitable for the space architecture, consulting on technical solutions to optimizing investment costs.

In addition, Hoang Sa Viet's customer care service is deployed 24/7, ready to support and answer all questions quickly and promptly. Thanks to that, customers can be completely assured during the process of choosing, installing and using elevator products.

3. Branch and showroom system nationwide

Hoang Sa Viet has built a system of branches and showrooms in many major cities such as Ho Chi Minh City, Hanoi, Da Nang, Dong Nai, Hung Yen, Phu Quoc, Long An ... to help customers conveniently experience, choose models directly and receive on-site consultation. Being present everywhere not only affirms prestige but also ensures the ability to provide quick and timely technical support in all situations, bringing maximum satisfaction to customers.

4. Specializing in hydraulic elevator products for families

At Hoang Sa Viet, customers can choose from a variety of pitless hydraulic elevators for their homes, from glass elevators, compact mini elevators, to high-end versions imported from Nidec Elevator. The products are flexibly designed to suit many architectural spaces, and all undergo a strict quality control process, ensuring absolute safety and long-term use.

With competitive prices and many attractive incentive packages, Hoang Sa Viet helps customers optimize costs while still owning high-standard products. In addition, transparent and clear warranty and maintenance policies are one of the advantages that make customers feel secure in choosing and sticking with the brand for a long time.

5. Outstanding warranty and maintenance policy, 24/7 support

Hoang Sa Viet is committed to providing professional warranty and maintenance services, with a team of technicians always ready to support 24/7 nationwide. We ensure quick handling of problems, perform periodic inspections to keep the elevator operating stably and absolutely safe.

Hoang Sa Viet's warranty policy is flexible, including genuine parts replacement and free consulting support. Therefore, customers can rest assured to use the product for a long time without worrying about technical problems arising.
